3/4"-10 Round Eye Nut ZP
Item Number: HRCAEN0750EG
$3.38
/ Each
Bulk pricing options available
Package Quantity:
1
- Zinc plated round eye nut with a 3/4"-10 female thread. The eye and the body are forged in one piece, so the eye takes a hook, shackle or sling link directly, and the flat base beds down on the face of the work and keeps the eye pulling square. Rated 2,400 lb working load limit. 1-1/2" inside the eye, 2-3/4" overall height. Sold each.
- Eye 1-1/2" ID. 2-3/4" H x 2-3/4" W. Base dia 1-9/16".
- 3/4"-10 female thread. 2,400 lb WLL. Zinc plated. Sold each.
- 3/4"-10 female thread, takes a 3/4" stud or bolt
- Rated 2,400 lb working load limit
- Eye 1-1/2" inside, takes a hook, shackle or sling link
$3.38
/ $3.38 Each
In Stock
Details
Vendor
EYE NUTS
Weight (lbs)
0.78
Type
Round Eye Nut
Thread Size
3/4"-10
Thread Pitch
10 TPI
Inner Diameter of Eye (IDE)
1-1/2"
Overall Height
2-3/4"
Overall Width
2-3/4"
Base Diameter (BD)
1-9/16"
Working Load Limit
2,400 lb
Material
Forged Steel
Finish
Zinc Plated
Sold As
Each
Key Features
- 3/4"-10 female thread, takes a 3/4" stud or bolt
- Rated 2,400 lb working load limit
- Eye 1-1/2" inside, takes a hook, shackle or sling link
- 2-3/4" overall height, 2-3/4" overall width
- Eye and body are forged in one piece, not welded
- Flat 1-9/16" base beds on the work so the eye pulls square
- Zinc plated finish, sold each
