5/16"-18 Round Eye Nut ZP
Item Number: HRCAEN0313EG
$0.79
/ Each
Bulk pricing options available
Package Quantity:
1
- Zinc plated round eye nut with a 5/16"-18 female thread. The eye and the body are forged in one piece, so the eye takes a hook, shackle or sling link directly, and the flat base beds down on the face of the work and keeps the eye pulling square. Rated 280 lb working load limit. 3/4" inside the eye, 1-7/16" overall height. Sold each.
- Eye 3/4" ID. 1-7/16" H x 1-3/8" W. Base dia 13/16".
- 5/16"-18 female thread. 280 lb WLL. Zinc plated. Sold each.
- 5/16"-18 female thread, takes a 5/16" stud or bolt
- Rated 280 lb working load limit
- Eye 3/4" inside, takes a hook, shackle or sling link
$0.79
/ $0.79 Each
In Stock
Details
Vendor
EYE NUTS
Weight (lbs)
0.11
Type
Round Eye Nut
Thread Size
5/16"-18
Thread Pitch
18 TPI
Inner Diameter of Eye (IDE)
3/4"
Overall Height
1-7/16"
Overall Width
1-3/8"
Base Diameter (BD)
13/16"
Working Load Limit
280 lb
Material
Forged Steel
Finish
Zinc Plated
Sold As
Each
Key Features
- 5/16"-18 female thread, takes a 5/16" stud or bolt
- Rated 280 lb working load limit
- Eye 3/4" inside, takes a hook, shackle or sling link
- 1-7/16" overall height, 1-3/8" overall width
- Eye and body are forged in one piece, not welded
- Flat 13/16" base beds on the work so the eye pulls square
- Zinc plated finish, sold each
